ASTM A192 Carbon Steel Tube



ASTM A192 Carbon Steel Tube

ASTM A192/ ASME SA192 Carbon Steel Pipe are used in Superheater, Reheaters, Economizers, heat exchangers, condensers, heat transfer equipment, similar pipes and for high-pressure settings, Major Industries Like Marine Industry, Petrochemical Industry, Food Processing Industry, Oil & Gas Industry Etc. These are available in different size, specification & thickness as per the clients requirements. We Supply ASME SA192 Grade A, Grade C & Grade D Tubes

Specification:

Standard : SA192 & A192 Tubes
Size : straight lengths up to 27.00 Meters with Outside Diameter ranging from 6.00mm to 8O.00mm and thickness ranging from 0.85mm to 6mm
Length : Double Random & Required Length, Single Random, & Custom Size Available
Pipes & Tubes End : Plain End, Beveled End, Treaded Protected With Plastic Caps
Shape : Round Pipes & Tubes, Coiled Tubes, “U” Shape Pipes & Tubes
Type : Seamless Sa192 & A192 Pipes & Tubes

Koryo steel , offers ASTM A192/ ASME SA192 Pipes & Tubes, which has excellent features such as rugged construction, precise dimensions, corrosion resistance, etc. ASTM A192 Carbon Steel Tube is highly recognised for its durability & sturdiness. It is available with us in diverse sizes & other related specifications to meet requirements of our prominent buyers.

Chemical Composition

Chemical Composition
C	Si	Mn	P	S	Mo	Cr	V
0.06-0.18	≤0.25	0.27-0.63	≤0.035	≤0.035	-	-	-

Mechanical Composition

Mechanical Properties
Tensile Strength (Mpa)	Yield Strength (Mpa)	Elongation(%)	Hardness (HRB)
≥325	≥180	≥35	≥77

Application

• Heat Exchangers
• Condensers
• Pulp & Paper Industry
• Chemical Equipment
• Sea Water Equipment
• Power Generation
